We design LED based UV curing systems which offer superior control and output stability, while providing reduced downtime and a lower cost of ownership.
LED UV SYSTEMS
LED Ultraviolet Curing is an Innovative Technology.
LED is a compact technology enabling more flexible form factors. The compactness of the system results in a smaller footprint.
Learn more about how LED UV curing systems from OXYTECH SYSTEMS™ can improve your productivity and reduce downtime for scheduled maintenance.
Air or water cooled options for consistent cooling
No warm up time or cool down time
Enhanced substrate versatility
High watt per cm² wavelength output options at 365, 385, 395, 405 nm
High output LED chip technology with dramatic energy savings and, payback potential
Curing is VOC free with no ozone generated
Significantly smaller footprint than conventional UV
More energy efficient than conventional UV systems
Sheetfed, Web, Flexo, Label, Packaging, Corrugated, Gravure, and Industrial Applications
LED technology is fundamentally a more compact technology than traditional ultraviolet lamps enabling much more flexible form factors. The compactness of LED systems, along with the fact that shuttering and air extraction systems are no longer necessary results in a much smaller footprint for the ultraviolet curing system.
There are 4 different LED UV emitters. They generate wavelengths from light emitting diodes (LED) at specific light spectrums of 365, 385, 395 and 405nm. This way people can choose the exact LED based on the spectrum they need for their ink or coating. The reason LED UV emitters are so energy efficient is that they emit only the exact spectrum needed and not any of the unused wavelengths. This saves electricity.
Mercury vapor lamps produce all wavelengths between 260nm and 440nm (nanometers) with various peaks. Some of the energy from a mercury vapor system will be in the infrared spectrum.
LED UV inks and coatings should be tuned to the specific wave length that an LED curing system is producing while conventional UV inks and coating are not specific because mercury vapor lamps cover all of the wavelengths.
An LED based system can offer superior control and stability of output while providing reduced downtime, long lifetimes, and low costs of ownership.
Learn more about how LED UV curing systems from OXYTECH SYSTEMS can improve your productivity and reduce downtime for scheduled maintenance.
New LED UV Worldwide Sheetfed Installations Include:
Komori Model GL440
Komori Model SX29
Komori Model S40
Komori Model G37
Komori Model G29
Komori Model GLX-840RP
Komori Model GX40RP
Komori Model GX840RP
Komori Model S29
